End plate for valve terminal HDM, Blind (to close off the system)
(List price: €33.76)
€33.76
List price:
€33.76 / piece
Your price:
€33.76 / piece
ERP-Info
Scale of prices
Quantity
Price
/
Sales info
Price unit:
1
Quantity unit:
piece
Content:
1 piece
excl. VAT and shipping
You can see the exact availability after logging in
In stock
SKU
106698
Customer product code
Type Number
5
Article name from customer
EAN-Code
4047322286824
End plate for valve terminal HDM, Blind (to close off the system), Temp. -10 ... More
You can see the exact availability after logging in
List price:
€33.76 / piece
Your price:
€33.76 / piece
ERP-Info
Scale of prices
Quantity
Price
/
Sales info
Price unit:
1
Quantity unit:
piece
Content:
1 piece
Productdata
End plate for valve terminal HDM, Blind (to close off the system), Temp. -10 °C to 60 °C
These compact valve terminals, with a maximum flow rate of 800 Nl/min, can be individually adapted to the specific conditions of each application thanks tot he wide range of functions and various input and intermediate plates.
Since each valve terminal is a customer-specific combination of a series of individual elements, the catalogue only lists the available input, intermediate and end plates as well as the different valve discs and the 25-pin multi-pole connectors.
Suitable for filtered, unlubricated or lubricated compressed air. If lubrication is used, it must be continuous.
Bistable (latching) version of manual control also available on request.
The operating pressure is based on the installed input plates.
Article No.
106698
Type No.
5
Module description
closed end-plate
Version
blind (to close off the system)
Min. temperature range
-10 °C
Max. temperature range
60 °C
Power input
0.6 W per pilot
Piloting
max. 16 (e.g. 16 spring return valves)
Protection IP
IP 65
Material
aluminium
Series
HDM
Manufacturer Art. No.
0227301500
Manufacturer/brand
Metal Work
Class name
MAX
Page No.
HK436
Customs tariff number
84818099
Country of origin
IT
