5/3-way valve low temp., man. 90° lever, G 1/4, m. exhaust., ret.
(List price: €114.98)
€114.98
List price:
€114.98 / piece
Your price:
€114.98 / piece
ERP-Info
Scale of prices
Quantity
Price
/
Sales info
Price unit:
1
Quantity unit:
piece
Content:
1 piece
excl. VAT and shipping
You can see the exact availability after logging in
In stock
SKU
149919
Customer product code
Type Number
70L2000900
Article name from customer
EAN-Code
4047322807043
5/3-way valve low temperature, manual 90° lever, G 1/4, mid-position exhauste... More
You can see the exact availability after logging in
List price:
€114.98 / piece
Your price:
€114.98 / piece
ERP-Info
Scale of prices
Quantity
Price
/
Sales info
Price unit:
1
Quantity unit:
piece
Content:
1 piece
Productdata
5/3-way valve low temperature, manual 90° lever, G 1/4, mid-position exhausted, return, p = vacuum … 10 bar, T = -40 … 60 °C
The series 70 low temperature valves in manually operated version with hand lever complement our range of traditional way valves of series 70. They represent a selection of the most commonly used manually operated way valves, which are manufactured with components for special low temperature applications. These valves are also suitable for use with vacuum.
Article No.
149919
Type No.
70L2000900
Operation
manually
Function
5/3 mid-position exhausted
Version
90° lever
Connection
G 1/4 IT
DN
7.5 mm
Flow rate measurement 1
flow rate at 6 bar and Δp 1 bar
Flow rate 1
1100 Nl/min
Flow rate measurement 2
flow rate at 6 bar and Δp 0.5 bar
Flow rate 2
750 Nl/min
Medium
filtered, dry and unlubricated compressed air
Required purity class in accordance w. ISO 8573-1
4.2.3
Min. operating pressure
-0.99 bar
Max. operating pressure
10 bar
Min. temperature range
-40 °C
Max. temperature range
60 °C
Valve body
aluminium
Piston
nickel-plated aluminium
Sealant
NBR
Spring
special steel
Series
series 70 low temperature
Manufacturer Art. No.
70L2000900
Manufacturer/brand
Metal Work
Class name
PLUS
Page No.
WEB
Customs tariff number
84818079
Country of origin
IT
Downloads
Variants
| Art. No. | Type No. | Attributes | Function | Version | Connection | Availability | Price | Options |
|---|---|---|---|---|---|---|---|---|
| 149923 | 70L2000700 | 5/3 mid-position pressurised | 90° lever | G 1/4 IT | You can see the exact availability after logging in | €114.98 List price: €114.98 / piece Your price: €114.98 / piece ERP-Info Scale of prices Quantity Price / Sales info Price unit: Quantity unit: piece Content: piece excl. VAT and shipping You can see the exact availability after logging in | ||
| 149911 | 70L2000400 | 5/2 bistable | 90° lever | G 1/4 IT | You can see the exact availability after logging in | €110.36 List price: €110.36 / piece Your price: €110.36 / piece ERP-Info Scale of prices Quantity Price / Sales info Price unit: Quantity unit: piece Content: piece excl. VAT and shipping You can see the exact availability after logging in | ||
| 149905 | 70L1000200 | 3/2 bistable | 90° lever | G 1/8 IT | You can see the exact availability after logging in | €85.90 List price: €85.90 / piece Your price: €85.90 / piece ERP-Info Scale of prices Quantity Price / Sales info Price unit: Quantity unit: piece Content: piece excl. VAT and shipping You can see the exact availability after logging in | ||
| 149909 | 70L1000400 | 5/2 bistable | 90° lever | G 1/8 IT | You can see the exact availability after logging in | €91.08 List price: €91.08 / piece Your price: €91.08 / piece ERP-Info Scale of prices Quantity Price / Sales info Price unit: Quantity unit: piece Content: piece excl. VAT and shipping You can see the exact availability after logging in | ||
| 149918 | 70L2001000 | 5/3 mid-position closed | 90° lever | G 1/4 IT | You can see the exact availability after logging in | €114.98 List price: €114.98 / piece Your price: €114.98 / piece ERP-Info Scale of prices Quantity Price / Sales info Price unit: Quantity unit: piece Content: piece excl. VAT and shipping You can see the exact availability after logging in | ||
| 149906 | 70L2000100 | 3/2 NC | 90° lever | G 1/4 IT | You can see the exact availability after logging in | €101.59 List price: €101.59 / piece Your price: €101.59 / piece ERP-Info Scale of prices Quantity Price / Sales info Price unit: Quantity unit: piece Content: piece excl. VAT and shipping You can see the exact availability after logging in | ||
| 149922 | 70L2000600 | 5/3 mid-position exhausted, latching | 90° lever | G 1/4 IT | You can see the exact availability after logging in | €114.98 List price: €114.98 / piece Your price: €114.98 / piece ERP-Info Scale of prices Quantity Price / Sales info Price unit: Quantity unit: piece Content: piece excl. VAT and shipping You can see the exact availability after logging in | ||
| 149913 | 70L1000900 | 5/3 mid-position exhausted | 90° lever | G 1/8 IT | You can see the exact availability after logging in | €95.38 List price: €95.38 / piece Your price: €95.38 / piece ERP-Info Scale of prices Quantity Price / Sales info Price unit: Quantity unit: piece Content: piece excl. VAT and shipping You can see the exact availability after logging in |
